| Turning diameter over bed(mm) | | φ800 mm |
| Swivel diameter of tool post(mm) | | φ540mm |
| Two top workpiece length(mm) | | 3000 mm |
| Workpiece weight between centers (kg) | | 300kg |
| Width of bed guide rail(mm) | | 400 mm |
| Spindle hole diameter(mm) | | φ52/80(Type B)/105(Type C)mm |
| Spindle speed range(r/min) | | (Three gears stepless)21-1500 r/min |
| | upscale(r/min) 162-1500 |
| | Mid-range(r/min) 66-500 |
| | low grade(r/min) 21-150 |
| Spindle speed change form | | Manual/automatic |
| Spindle end model | | ISO(GB)C6/D8 |
| Spindle front taper hole | | Mohs No. 6 |
| Spindle motor power(kw) | | 7.5/11kw |
| Spindle motor form | | Frequency conversion/servo |
| X|YZ axis travel(mm) | | X-axis: 410 mm / Z-axis: 600/850/1350/1850 mm |
| Size(mm) | 750mm | 2550×1750×2000 mm |
| 1000mm | 2750×1750×2000 mm |
| 1500mm | 3250×1750×2000 mm |
| 2000mm | 3700×1750×2000 mm |
| 3000mm | 4710×1750×2000 mm |
