| Maximum cutting length(mm) | 320 |
| Maximum weight of the workpiece(kg) | 500 |
| Ram reciprocation | System control20-100 |
| Ram vertical adjustment distance(mm) | 315 |
| Ram tilt angle(°) | 0-8° |
| Distance between the support surface of the cutter head and the front wall of the bed (mm) | 600 |
| Inserter bar maximum size(width*height)(mm) | 25x40 |
| Working desk size(mm) | 600x610 |
| Distance from work surface to the lowerend of the carriage(mm) | 490 |
| Worktable maximum longitudinal movement distance(mm) | 480/630 |
| Worktable ventical and horizontal maneuvering feed range(mm) | 480/560 |
| Worktable vertical and horizontal maneuvering feed range(mm) | 0.08-1.21 |
| X-direction servo motor | 7.7N.M |
| Y-direction servo motor | 7.7N.M |
| Servo main motor power(kw) | 7.5 |
| Main motor speed(r.p.m) | 0-8000 |
| Machine tool outline size (length*width*height)(mm) | 2180x1505×2285 |
| Machine weight | 3500 |
| System | KND1000MC |
